Capacitive Proximity Sensor | Cylindrical M12 PBT M12 Connector CR12 Connector Shielded and Non-Shielded | DADISICK

group name: Standard Capacitive Proximity Sensor

Min Order: 1 piece

brand name: DADISICK

model: Standard Capacitive Proximity Sensor | CR12 Connector Shielded and Non-Shielded | CR12-03NO-YAA-TA-P, CR12-03NC-YAA-TA-P, CR12-03PO-YAA-TA-P, CR12-03PC-YAA-TA-P, CR12-03PS-YAA-TA-P, CR12-03NS-YAA-TA-P, CR12-06NO-YAA-TA-P, CR12-06NC-YAA-TA-P, CR12-06PO-YAA-TA-P, CR12-06PC-YAA-TA-P, CR12-06PS-YAA-TA-P, CR12-06NS-YAA-TA-P, CR12-06NO-YBA-TA-P, CR12-06NC-YBA-TA-P, CR12-06PO-YBA-TA-P, CR12-06PC-YBA-TA-P, CR12-06PS-YBA-TA-P, CR12-06NS-YBA-TA-P, CR12-08NO-YBA-TA-P, CR12-08NC-YBA-TA-P, CR12-08PO-YBA-TA-P, CR12-08PC-YBA-TA-P, CR12-08PS-YBA-TA-P, CR12-08NS-YBA-TA-P

Delivery clauses under the trade mode: CIP

update time: Sun, 27 Apr 2025 04:35:06 GMT

contact supplier

Paramtents

Size: Cylindrical M12
Detection range: 1-3mm / 1-6mm / 1-8mm Adjustable
Case material: PBT
Connection type: M12 Connector
Output method: NPN NO/NC, PNP NO/NC,PNP NO&NC, NPN NO&NC
Degree of protection: IP67
Operating temperature: -25°C~+70°C

Packging & Delivery

Min Order1 piece

Briefing

Installation type: Shielded / Non-shielded
Detection range: 1-3mm / 1-6mm / 1-8mm Adjustable
Case material: PBT
Connection type: M12 Connector
Output method: NPN NO/NC, PNP NO/NC,PNP NO&NC, NPN NO&NC

Detailed

Standard Capacitive Proximity Sensor M12 Connector Shielded and Non-shielded Series Datasheet
Model	Output	Sensing distance	Connection	Maximum load current	Mounting	Operating voltage	Case material
CR12-03NO-YAA-TA-P	NPN NO	1-3mm Adjustable	M12 Connector	200mA	Shielded	10-30VDC	PBT
CR12-03NC-YAA-TA-P	NPN NC
CR12-03PO-YAA-TA-P	PNP NO
CR12-03PC-YAA-TA-P	PNP NC
CR12-03PS-YAA-TA-P	PNP NO&NC
CR12-03NS-YAA-TA-P	NPN NO&NC
CR12-06NO-YAA-TA-P	NPN NO	1-6mm Adjustable
CR12-06NC-YAA-TA-P	NPN NC
CR12-06PO-YAA-TA-P	PNP NO
CR12-06PC-YAA-TA-P	PNP NC
CR12-06PS-YAA-TA-P	PNP NO&NC
CR12-06NS-YAA-TA-P	NPN NO&NC

CR12-06NO-YBA-TA-P	NPN NO	1-6mm Adjustable	M12 Connector	200mA	Non-Shielded	10-30VDC	PBT
CR12-06NC-YBA-TA-P	NPN NC
CR12-06PO-YBA-TA-P	PNP NO
CR12-06PC-YBA-TA-P	PNP NC
CR12-06PS-YBA-TA-P	PNP NO&NC
CR12-06NS-YBA-TA-P	NPN NO&NC
CR12-08NO-YBA-TA-P	NPN NO	1-8mm Adjustable
CR12-08NC-YBA-TA-P	NPN NC
CR12-08PO-YBA-TA-P	PNP NO
CR12-08PC-YBA-TA-P	PNP NC
CR12-08PS-YBA-TA-P	PNP NO&NC
CR12-08NS-YBA-TA-P	NPN NO&NC

Electrical data
LED Display	Yes
Allowable ripple voltage	<10%
No-load current	<10mA
Leakage Current	<0.01mA
Voltage drop	<1.5v
Switching frequency	100HZ
Response time	0.1ms
Switching Hysteresis	<15%（Sr）
Repeat accuracy	<1.0%（Sr）
Degree of protection	IP67
Operating temperature	-25℃ to +70℃
Temperature Drift	<10%（Sr）
Load short-circuit protection / reverse polarity protection	Yes
Overload protection	220mA
Sensing surface material	PBT

Data sheet

Standard Series Capacitive Proximity Switch DataSheet
