Corrosion-resistant Inductive Proximity Sensor | LF18 Pre-wired Non-Shielded Cylindrical M18 Short Type 2M Cable | DADISICK
- group name
- Corrosion-resistant Inductive Proximity Sensor
- Min Order
- 1 piece
- brand name
- DADISICK
- model
- Corrosion-resistant Inductive Proximity Sensor | LF18 Pre-wired Non-Shielded | LF18-08NO-ZBA-3M-T, LF18-08NC-ZBA-3M-T, LF18-08PO-ZBA-3M-T, LF18-08PC-ZBA-3M-T, LF18-08NS-ZBA-4M-T, LF18-08PS-ZBA-4M-T, LF18-08HO-ZBD-2M-T, LF18-08HC-ZBD-2M-T, LF18-16NO-ZBA-3M-T, LF18-16NC-ZBA-3M-T, LF18-16PO-ZBA-3M-T, LF18-16PC-ZBA-3M-T, LF18-16NS-ZBA-4M-T, LF18-16PS-ZBA-4M-T, LF18-16HO-ZBD-2M-T, LF18-16HC-ZBD-2M-T
- Delivery clauses under the trade mode
- CIP
- update time
- Sun, 27 Apr 2025 04:41:49 GMT
Paramtents
Size: Cylindrical M18
Detection range: 8mm, 16mm
Case material: PTFE
Connection type: 2M Cable
Output method: NPN NO/NC，PNP NO/NC
Degree of protection: IP67
Operating temperature: -25°C~+70°C (248~343K)
Packging & Delivery
-
Min Order1 piece
Briefing
Detection range: 8mm, 16mm
Case material: PTFE
Connection type: 2M Cable
Output method: NPN NO/NC，PNP NO/NC
Case material: PTFE
Connection type: 2M Cable
Output method: NPN NO/NC，PNP NO/NC
Detailed
|
Corrosion-resistant Inductive Proximity Sensor M18 Pre-wired Non-Shielded Short Type Series Datasheet
|
||||||||
|
Model
|
Output | Sensing distance | Connection | Maximum load current | Mounting | Operating voltage | Case material |
|
LF18-08NO-ZBA-3M-T | NPN,NO | 8mm | 2 M cable | 200mA | Non-shielded | 10-30VDC | PTFE | |
LF18-08NC-ZBA-3M-T | NPN,NC | |||||||
LF18-08PO-ZBA-3M-T
| PNP,NO | |||||||
LF18-08PC-ZBA-3M-T
| PNP,NC | |||||||
LF18-08NS-ZBA-4M-T
| NPN NO+NC | |||||||
LF18-08PS-ZBA-4M-T | PNP NO+NC | |||||||
LF18-08HO-ZBD-2M-T | NO | 10-60VDC | ||||||
LF18-08HC-ZBD-2M-T | NC | |||||||
LF18-16NO-ZBA-3M-T | NPN,NO | 16mm | 2 M cable | 200mA | Non-shielded | 10-30VDC | PTFE | |
LF18-16NC-ZBA-3M-T
| NPN,NC | |||||||
LF18-16PO-ZBA-3M-T | PNP,NO | |||||||
LF18-16PC-ZBA-3M-T | PNP,NC | |||||||
LF18-16NS-ZBA-4M-T
| NPN NO+NC | |||||||
LF18-16PS-ZBA-4M-T
| PNP NO+NC | |||||||
LF18-16HO-ZBD-2M-T
| NO | 10-60VDC | ||||||
LF18-16HC-ZBD-2M-T
| NC | |||||||
|
Electrical data
|
|||
|
LED display
|
Yes
|
||
|
Allowable ripple voltage
|
<10%
|
||
|
No-load current
|
<10mA
|
||
Leakage current | <0.01mA | ||
Voltage drop | <1.5v | ||
Switching frequency | 500Hz (Sensing distance 8mm) 150Hz (Sensing distance 16mm) | ||
Response time | 0.5ms (Sensing distance 8mm) 1ms (Sensing distance 16mm) | ||
Switching hysteresis | <15%（Sr） | ||
Repeat accuracy | <1.0%（Sr） | ||
Degree of protection | IP67 | ||
Operating temperature | -25℃ to +70℃ | ||
Temperature drift | <10%（Sr） | ||
Load short-circuit protection / reverse polarity protection | Yes | ||
Overload protection | 220mA | ||
Sensing surface material | PTFE | ||
Data sheet
